Automatic screw-and-disc type load brake with corrosion protected componentsForged suspension and load hooks, manufactured from non-aging, high alloy tempering steel, yield under overload instead of breakingTwo guide rollers and a heat treated load sheave with 4 precision machined chain pockets ensure smooth operation of the chain The construction prevents a blocking and slipping of the hand chain| Code | Model | Rated Load [Ton] |
Standard Lift [m] |
Test Load [Ton] | Efforts Required at Capacity[N] | Diameter of Load Chain [mm] | No.of Load Chains |
|
Net Weight [kg] | Extra Weight Per Meter of extra list [kg] | |||||||||||
| C005 | HSZ-50C | 0.5 | 2.5 | 0.75 | 262 | 6 | 1 | 142 | 126 | 28 | 280 | 9.5 | 1.7 | ||||||||
| C010 | HSZ-100C | 1 | 2.5 | 1.5 | 314 | 6 | 1 | 142 | 126 | 32 | 300 | 10.5 | 1.7 | ||||||||
| C015 | HSZ-150C | 1.5 | 2.5 | 2.25 | 343 | 8 | 1 | 178 | 142 | 38 | 360 | 17.5 | 2.4 | ||||||||
| C020 | HSZ-200C | 2 | 2.5 | 3 | 318 | 6 | 2 | 142 | 126 | 40 | 380 | 14.5 | 2.5 | ||||||||
| C030 | HSZ-300C | 3 | 3 | 4.5 | 347 | 8 | 2 | 178 | 142 | 44 | 470 | 23 | 3.7 | ||||||||
| C050 | HSZ-500C | 5 | 3 | 7.5 | 382 | 10 | 2 | 210 | 165 | 50 | 600 | 35 | 5.3 | ||||||||
| C100 | HSZ-1000C | 10 | 3 | 12.5 | 390 | 10 | 4 | 358 | 165 | 64 | 730 | 68 | 9.7 | ||||||||
| C200 | HSZ-2000C | 20 | 3 | 25 | 390 | 10 | 8 | 580 | 195 | 82 | 1000 | 155 | 19.4 | ||||||||
| C300 | HSZ-3000C | 30 | 3 | 37.5 | 394 | 10 | 10 | 688 | 394 | 82 | 1050 | 233 | 23.9 | ||||||||
