Shackle suspension pointSuitable for pulling and lifting at angles across the beamUp to 45° side loading and 15° cross loadingHighly flexible – for lifting, pulling or as asemi-permanent anchor pointEvenly distributed loads achieved through maximum jaw surface area| Code | Model | Capacity Load [t] | Test Load [kn] | I-Beam Width Range [mm] | Weight[kg] |
| WGC 010 | WGC-1 | 1 | 1.5 | 75-220 | 5.5 |
| WGC 020 | WGC-2 | 2 | 3 | 75-220 | 6.6 |
| WGC 030 | WGC-3 | 3 | 4.5 | 80-320 | 12.5 |
| WGC 050 | WGC-5 | 5 | 7.5 | 80-320 | 17.5 |
| WGC 100 | WGC-10 | 10 | 15 | 80-350 | 23 |
