| Item | Chain Size | WLL | Main Dimensions | Weight | ||||||
| mm | ton | A | B | D | a | b | d | SxX | KG | |
| 8-WMLA-06 | 6 | 2.36 | 135 | 75 | 18 | 54 | 25 | 13 | 7*25 | 1.18 |
| 8-WMLA-07 | 7 | 3.15 | 135 | 75 | 18 | 60 | 38 | 13 | 7*25 | 1.24 |
| 8-WMLA-08 | 8 | 4.25 | 135 | 90 | 22 | 70 | 34 | 16 | 8*28 | 2.2 |
| 8-WMLA-10 | 10 | 6.7 | 160 | 100 | 26 | 85 | 40 | 18 | 11*35 | 3.4 |
| 8-WMLA-13 | 13 | 11.2 | 180 | 110 | 32 | 115 | 50 | 22 | 13*49 | 6.1 |
| 8-WMLA-16 | 16 | 17 | 200 | 140 | 36 | 140 | 65 | 26 | 17*55 | 9.98 |
| 8-WMLA-18 | 18 | 21.2 | 260 | 180 | 45 | 180 | 100 | 32 | 18*59 | 18.9 |
| 8-WMLA-20 | 20 | 26.5 | 340 | 190 | 50 | 180 | 100 | 32 | 20*64 | 22.6 |
| 8-WMLA-22 | 22 | 31.5 | 350 | 190 | 50 | 180 | 100 | 36 | / | 25.2 |
| 8-WMLA-26 | 26 | 45 | 400 | 200 | 56 | 180 | 100 | 40 | / | 35.2 |
| 8-WMLA-28 | 28 | 50 | 430 | 220 | 63 | 180 | 100 | 45 | / | 47 |
| 8-WMLA-32 | 32 | 63 | 460 | 250 | 72 | 200 | 110 | 50 | / | 66.46 |
